Sleeve, webbing zipper 3 in 1, webbing 3 in 1 Sew, press hem, press stop, zip up, etc

High rotational speed: 4000 revolutions per minute

Maximum trace length: 4mm

Pin stroke: 31.8mm

Foot press lift: Manual ≥5mm, knee control ≥13mm

Machine needle: DB*1

Rotary shuttle: An automatic lubricating rotary shuttle for wire cutting

Feeding method: It adopts a feeding press foot and two lower teeth combined feeding, and the upper feeding amount is adjustable

Feeding pressure foot fabric feeding capacity: 8mm

Feeding foot lift: 2.5mm - 5mm

Upper differential feeding differential ratio: Surplus ≥ 4:1 (for needle pitches below 2.5), deficit ≤ 2:1 The lower differential feeding ratio: shrinkage seam 1:1.5, extension seam 1:0.5

The upper differential feeding is driven by a motor and adjusted by buttons

The lower differential feeding is driven by a motor and adjusted by buttons

It is equipped with one-click switching of the upper and lower difference momentum

The number of segmented needles and the momentum of the segmented difference can be adjusted, and the momentum of the segmented difference can be set to 15

Wire cutting method: Rotary cutter
