Collar, front suit, etc

Adopting a built-in direct-drive servo motor, the machine achieves rapid start-up and highly accurate braking, significantly reducing noise, vibration and power consumption. Compared with conventional drive systems, it cuts energy use by more than 35 %. It is ideal for sewing all kinds of shirts, suits and similar garments—especially for collars, plackets and other critical areas—maintaining consistent forward and reverse stitch length even at high speed

Stitch length: 0-5mmg

Press foot height: 0-9mm

High-speed speed: 5000s.p.m

Cutter needle group: one of 1/8, 1/4, 3/16, 5/32 is optional

Independent stepper motor control

There is a reverse seam function independently controlled by the stepper motor

Press foot height: 0-9mm range adjustment, independent control by the stepper motor

The spindle adopts AC servo motor direct drive

With electronic clamp, clamping time (Angle) can be adjusted through the control panel

Needle rod and edge cutter action can be synchronous and asynchronous

Oil supply lubrication: pick rod, tool rod and tool rod sleeve, needle rod, needle rod sleeve using grease lubrication

Blanking space: 30mm*50mm

With electronic clamp, clamping time (Angle) can be adjusted through the control panel

Use electronic loose wire

One-click electronic switching function is used in the sewing process
